Fuel Service Tool (FST16)

$250.00

The multipurpose, 16 oz Affinity EG Fuel Service Tool can be used to clean both gasoline fuel induction systems through the throttle body and fuel injectors/combustion chambers when connected to the fuel rail. This professional-grade tool is designed with a clear tank to allow the cleaner level to be monitored during the service.

Compare Added Add to Wishlist Browse Wishlist
SKU: FST16 Category: Tags: ,
SKU: FST16 Category: Tags: ,
Patented: US Pat. Nos. 11,079,018, 11,662,021 - US Des. Pat. Nos. D927,636, D958,927, D958,528
Features of Fuel Service Tool (FST16):
  • Professional, durable design
  • Clear tank allows fuel cleaner level to be monitored during service
  • Service valve to control process flow of the fuel system cleaners
  • Rectus style, female quick connect for adapter connection
  • For fuel induction service use Affinity EG flexible fuel induction service ‘S’ adapter #31608S (not included)
  • For fuel injection service use Affinity EG fuel injection kit #FIKM000 (not included)

Additional information

Weight 3 lbs

DESCRIPTION

  • Professional, durable design
  • Clear tank allows fuel cleaner level to be monitored during service
  • 16 oz cleaner capacity
  • Use with fuel induction cleaner such as Wynn’s® Clean-SweepTM Intake/Induction Cleaner (ZW69116)
  • Use with fuel injection cleaners such as  Wynn’s® V.I.C. (ZW61510)
  • Service valve to control process flow of the fuel system cleaners
  • Rectus style, female quick connect for adpater connection
  • Compact, low cost design
  • For fuel induction service use Affinity EG flexible fuel induction service ‘S’ adapter #31608S (not included)
  • For fuel injection service use Affinity EG fuel injection kit #AEG-FIK (not included)
  • US Pat. No. 11,079,018 – US Des. Pat. Nos. D927,636, D958,927, D958,528

FUEL INJECTION SERVICE:

  • Depressurize tool before removing fill cap. Fill with injection cleaner.
  • Attached required fuel injection adapter to vehicle and service tool. Disengage vehicle fuel pump.
  • Set tool pressure required for engine. Open service hose valve and start engine. Run all cleaner until engine stops.
  • Remove tool & fuel injection adapter. Re-engage fuel pump.

FUEL INDUCTION SERVICE:

  • Depressurize tool before removing fill cap. Fill with injection cleaner.
  • Attach “S” Tool or Flex Nozzle Tool for induction service.
  • Close service hose valve and set tool pressure to 60 psi.
  • Install “S” tool in fresh air tube at throttle plate, or set Flex Nozzle Tool from throttle plate with fresh air tube removed (disconnect MAF sensor).
  • Run service on warm engine at 1200 RPM. Blow out 3-4 times during service to strip soot/carbon and clear induction system.
  • After service, run 10 min. then drive briskly to clear induction system.
  • Reconnect MAF sensor and clear any engine codes.
Service Instructions

FOR FUEL INJECTION:

① Depressurize tool before removing fill cap. Fill with injection cleaner.

② Attached required fuel injection adapter to vehicle and service tool. Disengage vehicle fuel pump.

③ Set tool pressure required for engine. Open service hose valve and start engine. Run all cleaner until engine stops.

④ Remove tool & fuel injection adapter. Re-engage fuel pump.

FOR FUEL INDUCTION:

① Depressurize tool before removing fill cap. Fill with injection cleaner.

② Attach “S” Tool or Flex Nozzle Tool for induction service.

③ Close service hose valve and set tool pressure to 60 psi.

④ Install “S” tool in fresh air tube at throttle plate, or set Flex Nozzle Tool from throttle plate with fresh air tube removed (disconnect MAF sensor).

⑤ Run service on warm engine at 1200 RPM. Blow out 3-4 times during service to strip soot/carbon and clear induction system.

⑥ After service, run 10 min. then drive briskly to clear induction system.

⑦ Reconnect MAF sensor and clear any engine codes.
